SYH T5 LED Tubes is dedicated to achieve end-user friendly performance, we keep working on the goals of super durability, highest lumen output, lowest consumption, top security structural design under this theory and our constant effort, SYH T5 LED Tubes is widely approved in all over the world.
|
Optical/Electrical Data |
|
|
|
|
|
|
Model |
T5 Tube light Series |
||||
|
Item |
Symbol |
L=60CM/2FT |
L=90CM/3FT |
L=120CM/4FT |
L=150CM/5FT |
|
Rate Power |
w |
9w |
14 |
18w |
22w |
|
Size |
|
Standard and Could be customized |
|||
|
Input Voltage |
V |
AC220-240V / AC100-277V / AC100-347V |
|||
|
Color Temperature |
CCT |
2700K-6500K |
|||
|
Luminous efficiency |
lm/w |
180lm/w |
|||
|
CRI |
|
>80 |
|||
|
Frequency |
Hz |
50Hz-60Hz |
|||
|
Power Factor |
PF |
>0.95 |
|||
|
View Angle |
Degree |
120 degree |
|||
|
Working Voltage |
V |
Constant DC30-42V and Could be customized |
|||
|
Housing Material |
/ |
Aluminum+PC |
|||
|
Protection Class |
IP |
IP44 |
|||
|
Certificate |
|
DLC UL cUL CE ROHS |
|||
|
Control protocol(s) |
|
Dimmable 0-10V,Triac |
|||
|
Temperature |
℃ |
Operating:-30℃~ +45℃ Storge:-30℃~ +60℃ |
|||
|
Life Time |
/ |
50,000Hours |
|||
|
Warranty |
/ |
5 Years |
|||
